Fantic 125 XX 2T MX

ENGINE

Type Single-cylinder 2-strokes wtih intake reed valve and exhaust YPVS

Displacement 125 cc

Carburetor Mikuni ø38

Bore 54 mm

Stroke 54.5 mm

Compression ratio 8.6 ~ 10.7 : 1

Ignition system CDI

Starting system Kickstarter

Lubrication system Premix

Trasmission 6-speed

Clutch Wet, multiple-disc

CHASSIS

Frame type Aluminum semi double cradle

Caster angle 26°

Trail 109 mm

Rear frame Alluminum

Swingarm Aluminum with variable section and progressive link

Rims 21x1.60 – 19x1.85 Tyres 80/100x21 - 100/90x19

Brakes Hydraulic disc ø270mm - Hydraulic disc ø245mm

Front suspension KYB ø48 mm, fully adjustable, wheel travel 300 mm

Rear suspension KYB, fully adjustable, wheel travel 315 mm

OVERALL DIMENSIONS

Length 2135 mm

Width 825 mm

Height 1295 mm

Seat height 975 mm

Wheelbase 1445 mm

Curb weight 95 kg

Fuel tank capacity 9.0 l

Engine oil quantity 0.7 l
